Beamex MC6-T Multifunction Temperature Calibrator and Communicator

Product Details

The Beamex MC6-T combines a state-of-the-art temperature dry block with built-in multifunction process calibrator and communicator technology. It offers versatility that no other temperature calibrator can match, providing calibration capabilities for temperature, pressure, and various electrical signals as well as a multi-bus communicator for fieldbus instruments.

Measurement, generation and simulation capabilities
Temperature generation
Pressure measurement (internal barometric and external pressure modules)
Voltage measurement (±1 V and −1…60 VDC)
Current measurement (±100 mA) (internal or external supply)
Frequency measurement (0…50 kHz)
Pulse counting (0…10 Mpulse)
Switch state sensing (dry/wet switch)
Built-in 24 VDC loop supply (low impedance, HART impedance or FF/PA impedance)
Voltage generation ( ±1 V and −3…24 VDC)
Current generation (0…55 mA) (active/passive, i.e. Internal or external supply)
Resistance measurement, two simultaneous channels (0…4 kΩ)
Resistance simulation (0…4 kΩ)
RTD measurement, two simultaneous channels
RTD simulation
TC measurement, two simultaneous channels (universal connector/mini-plug)
TC simulation
Frequency generation (0…50 kHz)
Pulse queue generation (0…10 Mpulse)
HART communicator
FOUNDATION Fieldbus communicator
Profibus PA communicator
(Some functions are optional)
